D-Link 8-Port Desktop Gigabit PoE+ Switch

Availability: 3 in stock

- +

8,437.00 Including all taxes

Accepted Payment Methods

About This Product

Something of a powerhouse when it comes to Power-over-Ethernet switches, this compact beauty offers PoE to 802.3af/at standard across all eight Gigabit Ethernet ports, at up to 30 Watts per port with a power budget total of 140 Watts. Which, put simply, means you can power devices such as access points, IP phones and video surveillance cameras simply by plugging them in with an Ethernet cable – no additional power required.
The DGS-1008MP features 8 x 10/100/1000BASE-T ports that support the IEEE 802.3at PoE+ protocol. Each of the 8 PoE+ ports can supply up to 30 watts with a total PoE power budget of 140 watts. PoE is especially suitable for devices that are far from power outlets or when you want to minimise the clutter of extra cables.
No configuration is required and installation is quick and easy. Support for Auto MDI/MDI-X on all ports eliminates the need for crossover cables when connecting to another switch. Auto- Negotiation on each port senses the link speed of a network device (10, 100 or 1000 Mbps) and intelligently adjusts for compatibility and optimal performance. The switch has been designed without fans ensuring silent operation wherever it is installed. With wire-speed filtering and store-and-forward switching, the DGS-1008MP maximises network performance while minimising the transmission of bad network packets.
DGS-1008MP switches feature both D-Link Green 3.0 Technology and IEEE802.3az Energy Efficient Ethernet (EEE) to cut operating costs without sacrificing operational performance or functionality. With D-Link Green technology, the switches constantly monitor the link status and network utilisation of every port. The switches also automatically detect cable length and can reduce transmission power usage for shorter cables. By pairing EEE capable devices with DGS-1008MP switches organizations can drastically reduce power consumption by automatically putting ports into a sleep mode when not being used.

Key Features & Highlights

  • High-Speed Networking
  • Eight 10/100/1000 Mbps Ethernet ports
  • Full/half-duplex for 10/100 Mbps Ethernet and full-duplex for 1000 Mbps Ethernet Reliability
  • IEEE 802.3x Flow Control
  • Store-and-forward switching scheme
  • RoHS compliant Easy Setup
  • Plug-and-play installation
  • Auto MDI/MDI-X crossover on all ports Desktop and Rackmount Design
  • Rack-mountable 11” metal casing (1U)
  • Fanless design PoE Functionality
  • IEEE 802.3at-compliant
  • 125 W total power budget
  • Up to 30 W power output per port

Technical Specifications

Management features

Switch type Unmanaged

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity 8
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)

Network

Networking standards IEEE 802.3ab, IEEE 802.3at, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
Full duplex Yes
Auto MDI/MDI-X Yes

Data transmission

Switching capacity 16 Gbit/s
MAC address table 8000 entries
Store-and-forward Yes
Packet forwarding rate (1 Gbps) 14880 pps
Packet forwarding rate (100 Mbps) 148800 pps
Packet forwarding rate (10 Mbps) 1488000 pps
Packet buffer memory 0.192 MB

Design

Rack mounting Yes
Form factor 1U
Product colour Black
LED indicators Yes

Power

AC input voltage 100 – 240 V
AC input frequency 50 – 60 Hz
Power consumption (typical) 13.5 W

Power over Ethernet (PoE)

Power over Ethernet (PoE) Yes
Power over Ethernet plus (PoE+) ports quantity 8
Total Power over Ethernet (PoE) budget 140 W

Operational conditions

Operating temperature (T-T) 0 – 40 °C
Storage temperature (T-T) -10 – 70 °C
Operating relative humidity (H-H) 0 – 95%
Storage relative humidity (H-H) 5 – 95%

Weight & dimensions

Width 280 mm
Depth 180 mm
Height 44 mm
Weight 1.84 kg

Packaging data

Package width 262 mm
Package depth 391 mm
Package height 102 mm
Package weight 2.85 kg

Technical details

Shipping (inner) case height 28.5 cm
Shipping (inner) case width 40.6 cm
Shipping (inner) case length 54.5 cm
Shipping (inner) case net weight 14.2 kg
Products per shipping (inner) case 5 pc(s)
Pallet gross weight (air) 563.8 kg
Master (outer) cases per pallet (air) 36 pc(s)
Products per pallet (air) 180 pc(s)
Pallet gross length 110 cm
Pallet gross width 120 cm
Pallet height (air) 193.5 cm
Pallet gross weight (sea) 563.8 kg
Master (outer) cases per pallet (sea) 36 pc(s)
Products per pallet (sea) 180 pc(s)
Pallet height (sea) 193.5 cm
Shipping (inner) case gross weight 15.3 kg

Logistics data

Harmonized System (HS) code 85176990
Manufacturer Part Number

DGS-1008MP/IN

Brand

DLINK

UPC / EAN

0790069428104

SKU

GD443C571N

Category

Network Switches

Subcategory

Lan Switch Layer 3

Switch type

Unmanaged

Basic switching RJ-45 Ethernet ports quantity

8

Basic switching RJ-45 Ethernet ports type

Gigabit Ethernet (10/100/1000)

Networking standards

IEEE 802.3ab, IEEE 802.3at, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x

Full duplex

Yes

Auto MDI/MDI-X

Yes

Switching capacity

16 Gbit/s

MAC address table

8000 entries

Store-and-forward

Yes

Packet forwarding rate (1 Gbps)

14880 pps

Packet forwarding rate (100 Mbps)

148800 pps

Packet forwarding rate (10 Mbps)

1488000 pps

Packet buffer memory

0.192 MB

Rack mounting

Yes

Form factor

1U

Product colour

Black

LED indicators

Yes

AC input voltage

100 – 240 V

AC input frequency

50 – 60 Hz

Power consumption (typical)

13.5 W

Power over Ethernet (PoE)

Yes

Power over Ethernet plus (PoE+) ports quantity

8

Total Power over Ethernet (PoE) budget

140 W

Operating temperature (T-T)

0 – 40 °C

Storage temperature (T-T)

-10 – 70 °C

Operating relative humidity (H-H)

0 – 95%

Storage relative humidity (H-H)

5 – 95%

Width

280 mm

Depth

180 mm

Height

44 mm

Weight

1.84 kg

Package width

262 mm

Package depth

391 mm

Package height

102 mm

Package weight

2.85 kg

Shipping (inner) case height

28.5 cm

Shipping (inner) case width

40.6 cm

Shipping (inner) case length

54.5 cm

Shipping (inner) case net weight

14.2 kg

Products per shipping (inner) case

5 pc(s)

Pallet gross weight (air)

563.8 kg

Master (outer) cases per pallet (air)

36 pc(s)

Products per pallet (air)

180 pc(s)

Pallet gross length

110 cm

Pallet gross width

120 cm

Pallet height (air)

193.5 cm

Pallet gross weight (sea)

563.8 kg

Master (outer) cases per pallet (sea)

36 pc(s)

Products per pallet (sea)

180 pc(s)

Pallet height (sea)

193.5 cm

Shipping (inner) case gross weight

15.3 kg

Harmonized System (HS) code

85176990

Product Documentation & Datasheet

Click the button below to view or download the official manufacturer documentation for this product:

📄 Download Official PDF Manual / Datasheet
