About This Product
Experience superior cooling performance with GIGABYTE CPU coolers. Designed with advanced thermal solutions and high-quality components, our coolers ensure optimal temperature regulation for your processor. From air to liquid cooling solutions, GIGABYTE offers reliability and efficiency, allowing you to push your CPU to its limits with confidence and peace of mind.
Key Features & Highlights
- Teflon tubing reduces coolant evaporation
- Magnetic top cover with replaceable light panel
- DIY-friendly fans with slide-lock and DAISY-CHAIN
- The ARGB fan lighting can be synchronized with other devices
- Universal fan and pump RPM control, compatible with all motherboard brands
📄 Product Documentation: Download Official Manual / Spec Sheet (PDF)
Technical Specifications
Performance
| Suitable location | Processor |
|---|---|
| Type | All-in-one liquid cooler |
| Fan diameter | 12 cm |
| Supported processor sockets | LGA 1200 (Socket H5), LGA 1700, LGA 1851, Socket AM4, Socket AM5 |
| Maximum airflow | 61.61 cfm |
| Maximum air pressure | 2.73 mmH2O |
| Bearing type | Ball bearing |
| Fan noise level (min) | 13.8 dB |
| Fan noise level (max) | 35.8 dB |
| Pump bearing technology | Ceramic bearing |
| Quantity per pack | 1 pc(s) |
| Pump motor speed (max) | 4500 RPM |
| Fan speed (min) | 500 RPM |
| Fan speed (max) | 2200 RPM |
Design
| Product colour | Black |
|---|---|
| Material | Aluminium, Copper |
| Base plate material | Copper |
| Number of fans | 3 fan(s) |
| Number of fan blades | 7 |
| Number of fins | 21 |
| Illumination LED | Yes |
| Illumination colour | Multi |
Power
| Thermal Design Power (TDP) | 300 W |
|---|
Weight & dimensions
| Radiator width | 40.3 cm |
|---|---|
| Radiator depth | 12 cm |
| Radiator height | 3.5 cm |
| Waterblock width | 6.6 cm |
| Waterblock depth | 6.6 cm |
| Waterblock height | 6.3 cm |
| Pump width | 6.6 cm |
| Pump depth | 6.6 cm |
| Pump height | 6.3 cm |
| Weight | 1.66 kg |
| Fan dimensions (W x D x H) | 120 x 25 x 3 mm |
| Package width | 465 mm |
| Package depth | 195.5 mm |
| Package height | 143 mm |
| Package weight | 2.34 kg |
Technical details
| Warranty period | 3 year(s) |
|---|
Packaging content
| CPU bracket(s) | Yes |
|---|
Other features
| Number of fans supported | 3 |
|---|---|
| Noise level | 36.9 dB |
