About This Product
Full size Z tower power at half the size
Get all the power of a full size tower at a fraction of the size. Re-engineered to fit full-height, full-length graphics while leaving room for upgrades and expansion, the Z2 SFF delivers high performance for your intensive workflow—from 3D design to real time ray tracing—now and in the future.
Key Features & Highlights
- Windows 11 Pro
- Intel Core i7-14700 (33MB Cache)
- 32GB (4800MHz) DDR5-SDRAM (2 x 16) & 1000GB SSD
📄 Product Documentation: Download Official Manual / Spec Sheet (PDF)
Technical Specifications
Processor
| Processor manufacturer | Intel |
|---|---|
| Processor family | Intel® Core™ i7 |
| Processor generation | Intel® Core™ i7 (14th gen) |
| Processor model | i7-14700 |
| Processor cores | 20 |
| Processor threads | 28 |
| Processor boost frequency | 5.4 GHz |
| Performance cores | 8 |
| Efficient cores | 12 |
| Performance-core Max Turbo Frequency | 4.8 GHz |
| Efficient-core Max Turbo Frequency | 4.2 GHz |
| Performance-core base frequency | 2.1 GHz |
| Efficient-core base frequency | 1.6 GHz |
| Processor cache | 33 MB |
| Processor cache type | Smart Cache |
| Processor socket | LGA 1700 |
| Processor base power | 65 W |
| Maximum turbo power | 219 W |
Memory
| Internal memory | 32 GB |
|---|---|
| Internal memory type | DDR5-SDRAM |
| Memory layout (slots x size) | 2 x 16 GB |
| Memory clock speed | 4800 MHz |
Storage
| Total storage capacity | 1 TB |
|---|---|
| Storage media | SSD |
| Optical drive type | No |
| Total SSDs capacity | 1 TB |
| Number of SSDs installed | 1 |
| SSD capacity | 1 TB |
| SSD interface | PCI Express 4.0 |
| NVMe | Yes |
| SSD form factor | M.2 |
Graphics
| Discrete graphics card | No |
|---|---|
| On-board graphics card | Yes |
| Discrete graphics card model | Not available |
| On-board GPU manufacturer | Intel |
| On-board graphics card family | Intel® UHD Graphics |
| On-board graphics card model | Intel UHD Graphics 770 |
Performance
| Market positioning | Performance |
|---|---|
| Product type | Workstation |
Network
| Ethernet LAN | Yes |
|---|---|
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Wi-Fi | No |
Ports & interfaces
| USB 2.0 ports quantity | 3 |
|---|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 4 |
| USB 3.2 Gen 2×2 Type-C ports quantity | 1 |
| DisplayPorts quantity | 2 |
| DisplayPort version | 1.4 |
| Ethernet LAN (RJ-45) ports | 1 |
| Combo headphone/mic port | Yes |
| Line-out | Yes |
| Line-in | Yes |
Expansion slots
| Number of 3.5" bays | 1 |
|---|
Power
| Power supply | 450 W |
|---|---|
| Power supply input voltage | 100 – 240 V |
| Power supply input frequency | 50 – 60 Hz |
Design
| Chassis type | SFF |
|---|---|
| Number of 2.5" bays | 1 |
| Product colour | Black |
| Introduction year | 2026 |
Software
| Operating system installed | Windows 11 Pro |
|---|
Display
| Display included | No |
|---|
Brand-specific features
| HP Support Assistant | Yes |
|---|---|
| HP Artificial Intelligence | AI Workstation |
| HP segment | Business |
Audio
| Audio chip | Realtek ALC3252 |
|---|
Weight & dimensions
| Width | 384 mm |
|---|---|
| Depth | 308 mm |
| Height | 100 mm |
| Weight | 5 kg |
Packaging data
| Package width | 100 mm |
|---|---|
| Package depth | 384 mm |
| Package height | 308 mm |
| Package weight | 5.9 kg |
