About This Product
High-Performance with webOS 6.0
webOS 6.0, upgraded in SoC and web engine, is available on SM5J for a smooth execution of several tasks. LG webOS smart signage platform enhances user convenience with intuitive GUI and provides to SI or/and developers simple app development tools such as SDK (Software Development Kit), SCAP, sample applications.
Various Sensor Connection
LG webOS smart signage platform helps to easily provide additional solutions by supporting simple connections with external sensors* such as GPIO, NFC/RFID, temperature sensors, etc., via USB plug-in.
Mobile & Web Monitoring
Through the Control Manager, the embedded web monitoring solution, you can control and monitor the status of the SM5J series displays in different locations in real-time. It is available on internet connected devices, allowing you to flexibly and rapidly respond to emergency situations.
Compatible with AV Control System
The SM5J series supports Crestron Connected® for high compatibility with professional AV controls to achieve seamless integration and automated control*, boosting business management efficiency.
Real-Time LG ConnectedCare Service
Maintenance is easy and fast with the optional LG ConnectedCare* service, a cloud service solution provided by LG. It remotely manages the status of displays in client workplaces for fault diagnosis and remote-control services, supporting the stable operation of clients’ businesses.
LG’s Simple Advertisement Helper, Promota
Using LG’s Promota* application, downloadable on a mobile device, you can easily create your own display contents. With Promota, you can add text and images to create an online profile for your business as well as deliver information such as event news, seasonal menus, promotions, and even more while recommending easy-to-use templates relevant to your industry.
Key Features & Highlights
- Brightness(Typ.) : 400 cd/m²
- Bezel : 13 mm (T/R/L), 18 mm (B)
- Depth : 55.5 mm
- Interface : HDMI(3) / USB 2.0 / RS232C / RJ45 / IR / Audio Out
- Built-in Speaker : 10W + 10W
Technical Specifications
Display
| Panel type | IPS |
|---|---|
| Display diagonal | 81.3 cm (32") |
| Display resolution | 1920 x 1080 pixels |
| Display brightness | 400 cd/m² |
| HD type | Full HD |
| Touchscreen | No |
| Response time | 10 ms |
| Contrast ratio (typical) | 1100:1 |
| Contrast ratio (dynamic) | 1000000:1 |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Haze rate | 1% |
Ports & interfaces
| HDMI ports quantity | 3 |
|---|---|
| HDMI version | 2.2 |
| HDMI input ports quantity | 3 |
| USB port | Yes |
| USB ports quantity | 1 |
| USB version | 2.0 |
| USB connector type | USB Type-A |
| Ethernet LAN (RJ-45) ports | 1 |
| Audio (L/R) out | 1 |
| RS-232C | Yes |
| Remote (IR) input | 1 |
Audio
| Built-in speaker(s) | Yes |
|---|---|
| Number of built-in speakers | 2 |
| RMS rated power | 20 W |
Design
| Product design | Digital signage flat panel |
|---|---|
| Placement supported | Indoor |
| Orientation | Horizontal/Vertical |
| Product colour | Black |
| Screen shape | Flat |
| VESA mounting | Yes |
| Panel mounting interface | 200 x 200 mm |
| Bezel width (bottom) | 1.8 cm |
| Bezel width (side) | 1.3 cm |
| Bezel width (top) | 1.3 cm |
Performance
| Purpose | Universal |
|---|---|
| Operating hours (hours/days) | 24/7 |
| HDCP | Yes |
| HDCP version | 2.2 |
Power
| Power consumption (typical) | 55 W |
|---|---|
| AC input voltage | 100 – 240 V |
| AC input frequency | 50 – 60 Hz |
| Heat dissipation | 187.67 BTU/h |
Computer system
| Computer system | Yes |
|---|---|
| Internal memory | 8 GB |
| Operating system installed | WebOS |
Weight & dimensions
| Display width | 729.4 mm |
|---|---|
| Display depth | 55.5 mm |
| Display height | 428.9 mm |
| Display weight | 5.7 kg |
| Width | 729.4 mm |
| Depth | 55.5 mm |
| Height | 428.9 mm |
| Weight | 5.7 kg |
| Width (with stand) | 729.4 mm |
| Depth (with stand) | 154.2 mm |
| Height (with stand) | 481 mm |
| Weight (with stand) | 6.5 kg |
Packaging content
| Remote control included | Yes |
|---|---|
| Cables included | AC, HDMI |
Operational conditions
| Operating temperature (T-T) | 0 – 40 °C |
|---|---|
| Operating relative humidity (H-H) | 10 – 80% |
Certificates
| Certification | CB / NRTL FCC Class "A" / CE |
|---|
Logistics data
| Harmonized System (HS) code | 85285210 |
|---|
Network
| Ethernet LAN | Yes |
|---|---|
| Wi-Fi | Yes |
Technical details
| Sustainability certificates | China Organic Product Certification, ENERGY STAR |
|---|
