About This Product
Smart-UPS 3000VA
APC Smart-UPS, 2700 Watts / 3000 VA,Input 230V / Output 230V, Interface Port DB-9 RS-232, USB, SmartSlot.
Includes: CD with software, Smart UPS signalling RS-232 cable, USB cable, User Manual.
Key Features & Highlights
- 3 kVA 2700 W
- Sealed Lead Acid (VRLA)
- Black
📄 Product Documentation: Download Official Manual / Spec Sheet (PDF)
Technical Specifications
Features
| Output power capacity | 3 kVA |
|---|---|
| Output power | 2700 W |
| Input frequency | 50/60 Hz |
| Surge energy rating | 365 J |
| Emergency Power Off (EPO) | Yes |
| Noise level | 53 dB |
| Audible alarm(s) | Yes |
Ports & interfaces
| USB 2.0 ports quantity | 1 |
|---|---|
| Serial ports quantity | 1 |
Battery
| Battery technology | Sealed Lead Acid (VRLA) |
|---|---|
| Typical backup time at full load | 5.5 min |
| Typical backup time at half load | 13.6 min |
| Battery recharge time | 3 h |
Design
| Product colour | Black |
|---|---|
| LED indicators | Yes |
Operational conditions
| Operating temperature (T-T) | 0 – 40 °C |
|---|---|
| Storage temperature (T-T) | -15 – 45 °C |
| Operating relative humidity (H-H) | 0 – 95% |
| Storage relative humidity (H-H) | 0 – 95% |
| Operating altitude | 0 – 3000 m |
| Non-operating altitude | 0 – 15000 m |
Certificates
| Certification | C-tick,CE,EN 50091-1,EN 50091-2,GOST,VDE, RoHS 7b |
|---|
Weight & dimensions
| Weight | 55.9 kg |
|---|
Packaging data
| Package weight | 65 kg |
|---|
Logistics data
| Products per pallet | 3 pc(s) |
|---|
Other features
| Interface | USB |
|---|---|
| Output connections | 8 x IEC 320 C13 1 x IEC 320 C19 2 x IEC Jumpers |
| Input connection type | IEC-320 C20, CEE 7 / EU1-16P, BS1363A |
| Dimensions (WxDxH) | 196 x 546 x 432 mm |
| Nominal output voltage | 230 V |
| Output voltage note | 220 – 240 |
| Filtering description | 0.3% IEEE/UL 1449 |
| Nominal input voltage | 230 V |
| Package dimensions (WxDxH) | 380 x 760 x 680 mm |
